304 Stainless Steel Hex Socket Head Cap Screw (A2) TITAN
Stainless Socket Screw- สินค้าใหม่
- สินค้านำเข้า
- สินค้าพร้อมส่ง
Product information
Stainless steel countersunk head screws with inch threads (or hexagonal threads) are screws with a flat head that recesses into the workpiece. They typically have a hexagonal hole and require a wrench to tighten. Their main properties are strength, durability, corrosion resistance, and rust resistance. They are ideal for automotive assembly, industrial machinery, and applications requiring a neat and clean finish.
Stainless steel material: Corrosion resistance, rust resistance, and durability.
Smooth countersunk head: The underside of the screw head forms an angle of approximately 82 degrees, allowing the screw head to recess into the material when tightened, creating a neat and clean finish.
Thread: Available in both full and half threads, depending on the application.
Tightening: Use a hex wrench to tighten, providing excellent torque resistance and a secure hold.
Common Uses: Stainless steel countersunk head screws with inch threads are commonly used in a variety of
applications, including:
- Automotive assembly
- Electrical appliances
- Industrial machinery
- Various installation and installation projects requiring a neat and clean finish.
Size | 3/16″ | 1/4″ | 5/16″ | 3/8″ | 1/2″ | 1/2″ | 5/8″ | 3/4″ |
Spiral | 24 | 20 | 18 | 16 | 12 | 13 | 11 | 10 |
UNC | UNC | UNC | UNC | UNC | UNC | UNC | UNC | |
Wrench | 5/32″ | 3/16″ | 1/4″ | 5/16″ | 3/8″ | 3/8″ | 1/2″ | 5/8″ |
Length | ||||||||
1/2″ | 1/2″ | 1/2″ | 1/2″ | |||||
5/8″ | 5/8″ | 5/8″ | 5/8″ | 3/4″ | ||||
3/4″ | 3/4″ | 3/4″ | 3/4″ | 1″ | ||||
1″ | 1″ | 1″ | 1″ | 1-1/4″ | 1″ | 1″ | ||
1-1/4″ | 1-1/4″ | 1-1/4″ | 1-1/4″ | 1-1/2″ | 1-1/4″ | 1-1/4″ | ||
1-1/2″ | 1-1/2″ | 1-1/2″ | 1-1/2″ | 2″ | 1-1/2″ | 1-1/2″ | 1-1/2″ | 1-1/2″ |
2″ | 2″ | 2″ | 2-1/2″ | 2″ | 2″ | 2″ | 2″ | |
2-1/2″ | 2-1/2″ | 2-1/2″ | 3″ | 2-1/2″ | 2-1/2″ | 2-1/2″ | 2-1/2″ | |
3″ | 3″ | 3″ | 3″ | 3″ | 3″ | 3″ | ||
3-1/2″ | 3-1/2″ | 3-1/2″ | 3-1/2″ | 3-1/2″ | ||||
4″ | 4″ | 4″ | 4″ | 4″ | ||||
5″ | 5″ | 5″ | ||||||
6″ | 6″ | 6″ |
